Introduction
CONTEC08E is an Electronic Sphygmomanometer with color LCD, features in concise interface and one-key operation, it can measure NIBP and SpO2(optional) accurately, and NIBP records can be reviewed by the memory button. The device is widely used in family, clinic and physical-examination center for routine test.Features
1)Small in volume, easy to operate, color LCD display, optional language interface(Chinese and English), strong in visibility.2)Be applicable for adult.
3)Start measuring manually, record each measurement data, and store up to 99 groups of data.
4)NIBP measurement results, measurement date and time can be stored.
5)Three data review interfaces: “Data list”, “Trend chart” and “Big font”.
6)Low battery and error information indication.
7)Automatic poweroff when there is no operation for a long time, achieves saving power.
8)Optional units: mmHg and kPa
9)SpO2 measurement function(SpO2 probe is necessary).
Performance
1) NIBP
Measurement method: Oscillometry
Measurement mode: upper-arm type
Measurement range: 0 kPa(0 mmHg) ~ 38.67 kPa(290 mmHg)
Resolution: 0.133 kPa(1 mmHg)
Accuracy: ±0.4 kPa(±3 mmHg)
PR measurement range: 40 bpm ~ 240 bpm
Inflation: automatic inflation by force pump
Deflation: automatic multistep deflation
Accessories
1)Cuff for adult2)User manual （GB only）on request for other Language
Physical characteristic
Dimension: 132 mm(L)×130 mm(W)×50 mm(H)Weight: 405g (including batteries)
Operation environment
Temperature: +5 ˚C ~ +40 ˚C
Relative humidity: 15 % ~ 85 %
Atmospheric pressure: 700 hPa ~ 1060 hPa
Storage environment:
Temperature: -20 ˚C ~ +55 ˚C
Relative humidity: ≤95 %
Atmospheric pressure: 700 hPa ~ 1060 hPa
