JYTOP
JYTOP KT88 Digital Brain Electric Activity Mapping EEG 16-channel Electroencephalogram Machine
JYTOP KT88 Digital Brain Electric Activity Mapping EEG 16-channel Electroencephalogram Machine
Precio habitual
$830.00 USD
Precio habitual
Precio de oferta
$830.00 USD
Precio unitario
por
Los gastos de envío se calculan en la pantalla de pago.
No se pudo cargar la disponibilidad de retiro
Product Description
KT88 Digital Brain Electric Activity Mapping collects EEG signal with electrodes, via integrated amplification, A/D transformation, PC auto-analysis, FFT, to form electroencephalogram that displays with color depth. The product is applicable for checking such diseases as epilepsy, intracranial inflammation, cerebrovascular diseases and brain tumors.
|
16 channels of EEG+2 channels of ECG (ECG is optional)
|
|
|
Sampling rate
|
100 dots/s
|
|
Accuracy
|
12bit
|
|
Input impedance
|
≥10MΩ
|
|
Patient leak current:
|
< 10µA
|
|
Noise level
|
≤5µVp-p
|
|
CMRR
|
≥90dB
|
|
Magnification multiple
|
10000
|
|
Display speed(paper speed)
|
5, 10, 15, 30, 60, 120 mm/s
|
|
Amplitude
|
1, 1.5, 2, 3, 5, 7.5, 10, 12, 15, 20, 30, 50 mm/50µV
|
|
Playback speed
|
1 time, 2 times, 3 times, 10 times, 20 times, 40 times, 60 times
|
|
50Hz interference suppression
|
≥30dB
|
